● Service Introduction

· Accurate alignment of data from multiple sources

· Data alignment based on as-built information：

1、OCR technology to extract key fields of as-built data and generate structured data reports
2、Reports are automatically associated, a relational database is generated, and the alignment is done automatically.
3、Manual review and correction of OCR recognition and alignment results

● Service Examples

· Alignment based on internal inspection data, industrial negative raw data:

1、Intelligent extraction of internal inspection data, spiral weld, straight weld information, volumetric defect information at the circumferential weld of the industrial negative and generation of the basic database, automatic completion of the alignment work
2、Manual review and analysis of alignment results

· Data fusion analysis:

1、Intelligent extraction of weld features in digitized images of industrial negatives, (volumetric defect and intersection weld features) to form a radiographic feature database;
2、Intelligent extraction of internal inspection signal features (volumetric defects and intersection weld features) to form a database of internal inspection signal features;
3、Correspondence relationships are automatically matched and precisely aligned to determine data consistency;
4、Combined with the intelligent same port recognition, pipe section information list and other information, to determine the unaligned weld seam. The accuracy of the alignment can be greatly improved compared with the simple table-to-table information data alignment.

Negative Weld Pattern Feature Extractor

● sort

Efficiently and accurately identifying abnormal weld bead conditions
Confirmation of wrong weld bead in the same port comparison can be solved.
